The difference between dredge pump and sand pump:

Published:

2023-12-19 16:50

Source:

Dredge pumps and sand gravel pumps are common heavy-duty pump equipment in the engineering field, playing an important role in the transportation of materials such as mud and gravel. Although they have similar functions, there are differences in some aspects.

1.Basic differences

No	Comparison point	ZG sand pump	ZN dredge pump
1	Application conditions	Sand mining and excavation	Dredging and dredging of rivers and lakes
2	design	Using international technology for optimization	China independent design
3	appearance.	Clamp connection	bolt connection
4	Impeller type	Closed-type 3-blade impeller	Closed-type 5-blade impeller
5	lubricating system	Grease Lubrication	thin oil lubrication
6	Model size	Minimum model 6 / 4, outlet diameter 4 inch	Minimum model ZN 250, outlet diameter 250mm (10 inch)

2.Basic Introduction

① ZG sand pump feature:

ZG series sand pumps are designed for handling sand and heavy abrasive slurries. They are designed with high hardness alloy materials and thickened overflow parts for excellent abrasion resistance. It is mainly used for continuous transportation of strongly abrasive materials whose particles are so large that they cannot be transported by general slurry pumps.

② ZN dredge pump feature:

ZN series dredge pumps are used in dredging process, usually used with dredger. The overflow parts are made of high chrome alloy, with the advantages of high head, large flow, high efficiency, good cavitation margin, etc. It is suitable for land reclamation, dredging, flood control, construction of new ports or expansion of existing ports.

As a professional manufacturer of large sand mining and dredging pumps, technology and design have been incorporated into the manufacturing to provide the best cost performance required.

If you have a project in sand mining, dredging, feel free to contact me, I will provide you a suitable pump solution.
